ARIS Electric Actuators
With its headquarters in Troisdorf, Germany, ARIS Stellantriebe GmbH brings more than 50 years of engineering expertise in electric actuator technology. ARIS is renowned for its compact, robust solutions and serves a global customer base in plant construction and industrial automation.
Nano
High-quality and compact electric actuators for industrial use.
– Robust aluminum housing
– Cover: plastic
– Protection class: IP 66 / IP 67
– Torque: 5 – 60 Nm
– Actuating time: 3 – 120 s/90°
– AC version has Synchronous motor, short-circuit-proof Drive
– DC version has brush motor
|
Product variations |
Actuating time AC |
Actuating time DC |
|
Nano S – 5-20Nm |
3 - 60 s/90° |
6 - 180 s/90° |
|
Nano M – 30-60Nm |
3 - 45 s/90° |
6 - 100 s/90° |
Nano+
– Robust aluminum housing
– Hood: aluminum
– Protection class: IP 66 / IP 67
– Torque: 5 – 500 Nm
– Actuating time: 0.8 – 150 s/90°
– Synchronous motor, short-circuit-proof Drive
|
Product variations |
Actuating time AC |
|
Nano+ S – 5-25Nm |
0.8 - 60 s/90° |
|
Nano+ M – 30-75Nm |
2.5 - 180 s/90° |
|
Nano+ L – 80-180Nm |
5 - 210 s/90° |
|
Nano+ XL – 250-500Nm |
20 - 150 s/90° |
Tensor 2
Electric Actuator Modular in design, variable and flexible in use
– Robust aluminum housing
– Protection class: IP 66 / IP 67
– Torque: 1 – 200 Nm
– Actuating time: 2 – 210 s/90°
– Flexible travel from 10° to 100 revolutions
– Position detection accuracy up to 0.03°
– Multi current power supply 85 – 265V AC or 24V DC
– Regulated torques and actuating times
|
Product variations |
Actuating time |
|
Tensor 2 S – 1-20Nm |
2 - 60 s/90° |
|
Tensor 2 M – 30-75Nm |
8 - 120 s/90° |
|
Tensor 2 L – 80-200Nm |
30 -210 s/90° |
ExTensor
Explosion-proof actuator
Fully electronic rotary, part-turn and modulating actuators
for potentially explosive zones 1,2 (gas) and 22 (dust)
Approvals / Labelling
ATEX:
II 2G Ex db IIC T6 Gb
II 2D Ex tb IIIC T80 °C Db
Ta -20 °C … +60 °C
EU type examination certificate IBExU22ATEX1066 X
IECEx:
Ex db IIC T6 Gb
Ex tb IIIC T80 °C Db
-20 °C ≤ Ta ≤ +60 °C
ExTR Ref. no. DE/IBE/ExTR22.0022/00
|
Product variations |
Actuating time |
|
ExTensor S 5-40Nm |
1-80 s/90° |
|
ExTensor M 50-75Nm |
5-120 s/90° |
|
ExTensor L 80-200Nm |
8-120 s/90° |
|
ExTensor XL 250-500Nm |
25-150 s/90° |
