Butterfly Valves
Butterfly Valve ABO Series 900
A range of rubber lined butterfly valves from DN32 to DN1600, standard valve having ductile iron body, stainless steel disc and EPDM liner, additional materials available.
Wafer Pattern or Lugged, flange accomodation PN6/10/16 and ANSI class 150.
Available bare shaft, manually operated, actuated via pneumatic or electric actuator.
Data Sheet Operating Instructions Installation Instructions Safety Instructions
Double Offset Butterfly Valve ABO Series 2E-5
High Performance double offset valve range from DN50 to DN400, available in carbon or stainless steel with RPTFE, PTFE+Inconel (Fire Safe) and Metal to Metal Seat options.
Wafer Pattern or Lugged, flange accomodation PN6/10/16/25/40, ANSI150 & 300, JIS10K and JIS16K all available.
ATEX Option available on request.
Available bare shaft, manually operated, actuated via pneumatic or electric actuator.
Data Sheet Operating Instructions Installation Instructions Safety Instructions
Triple Offset Butterfly Valve ABO Series 3E
High Performance triple offset valve range from DN150 to DN400, available in carbon or stainless steel with Stainless steel + graphite Seat for upto 500°C working temperature.
Wafer Pattern or Lugged, flange accomodation PN6/10/16/25/40, ANSI150 & 300, JIS10K and JIS16K all available.
ATEX Option available on request.
Available bare shaft, manually operated, actuated via pneumatic or electric actuator.
Data Sheet Operating Instructions Installation Instructions Safety Instructions
